Wired PIR Motion Sensor PIR-01
Product Details:
X
Product Description
Technical Specification
- Operating Voltage: DC9V~16V
- Detection Range: Vertical angle 60degree, Horizontal angle 110 degree, 12m
- Standby Current: NC≤15mA ; NO≤6mA
- Alarm Current: NC≤19mA ; NO≤18mA
- RF Immunity: > 20 V/m 10 – 1000 MHz
- Sensitivity: > 3300V/W
- White Light Immunity: > 8000 lux
- Noise(Vp-p): <200mV, (mVp-p)(25°C)
- Alarm Output: NC or NO
- Temperature Range: -10°C to +50°C
- Relative Humidity: 90% (25°C )
- Installation Mode: Wall mounted by bracket
- Installation Height: 2m
- Housing: High-impact ABS
- Dimensions: 107×59.5×39.5mm (HxWxD)
- Applications: For indoor use. Corridor, Office, Room, Museum, Library, Finance Room, Warehouse, etc.
