Heat Detector SM-04
Product Details:
X
Product Description
Technical Specifications
- Operating Voltage : DC9V-35V
- Standby Current : NC≤12mA ; NO≤22mA
- Alarm Current : NC≤3mA ; NO≤15mA
- RF Immunity : > 20 V/m 10 – 1000 MHz
- Sensitivity : class I, 3%/m
- White Light Immunity : > 8000 lux
- Noise(Vp-p): <200mV, (mVp-p)(25 C)
- Alarm Temperature : 57 Degree C (135F)
- Alarm Output : NC or NO, Led indication
- Alarm Volume : 80 square meters (with the installation height of 6m-12m), and 60 square meters (installation height of less than 6m)
- Temperature Range : -10 C to +50 C
- Relative Humidity: Less than 95% (25 C )
- Installation Mode: Ceiling Mounted
- Housing : High-impact ABS
- Dimensions : 100mm x 46mm (Dia.xH)
- Applications: For indoor Use
