Wireless Curtain PIR Motion Sensor CPIR-100A
Product Details:
X
Product Description
Technical Specification
- Operating Voltage: 2X3V “AA” Battery
- Detection Range: Vertical angle 15degree, Horizontal angle 90 degree, 9m
- Standby Current: less than 25uA
- Alarm Current: less than 15mA
- RF Immunity: > 20 V/m 10 – 1000 MHz
- Sensitivity: > 3300V/W
- Noise(Vp-p): <200mV, (mVp-p)(25°C)
- Transmitting Freq.: 433.92MHz
- Transmitting Distance: minimum 100m( in the open area)
- Temperature Range: -10°C to +50°C
- Relative Humidity: 90% (25°C )
- Installation Mode: Wall mounted by bracket or Ceiling Mounted
- Installation Height: 2m(Wall mounted by bracket), 5-9m (Ceiling Mounted)
- Housing: High-impact ABS
- Dimensions: 110×69.50x40mm (HxWxD)
- Applications: For indoor use. Corridor, Office, Room, Museum, Library, Finance Room, Warehouse, etc
