Wired Pet Immunity PIR Sensor PIR-04
Product Details:
X
Product Description
Technical Specification
- Operating Voltage: DC9V~16V
- Detection Range: Vertical angle 60degree, Horizontal angle 110 degree, 12m
- Standby Current: NC≤15mA ; NO≤12mAa
- Alarm Current:NC≤100mA ; NO≤30mA
- Temper Switch Current: NC,12VDC,100mA max
- RF Immunity: > 25 V/m 10 – 1000 MHz
- Sensitivity: > 3300V/W
- White Light Immunity: > 8000 lux
- Pet Immunity: ≤25Kg
- Noise(Vp-p): <200mV, (mVp-p)(25°C)
- Alarm Output: NC or NO
- Temperature Range: -5°C to +50°C
- Relative Humidity: 90% (25 ? )
- Installation Mode: Wall mounted by bracket
- InstallationHeight: 2m
- Housing: High-impact ABS
- Dimensions: 107x58x39mm(HxWxD)
- Applications: For indoor use. Corridor, Office, Room, Museum, Library, Finance Room, Warehouse, etc.
