ST-IP-WP-010- 8MP Network Bullet Camera

Smart Function

Human detection

Main Chipset

T40XP

Image Sensor

1/2.7″, 8MP progressive scan ultra-low illumination CMOS SC8238

Effective Pixels

8MP

Min. Illumination

Color: 0.1Lux@F1.2; B&W: 0Lux@F1.2(IR on)

Lens

4 mm

IR Distance

20-30M (30-IR light)

Noise Reduction

3D noise reduction

WDR

DWDR (off/ low / medium / high)

Mirror

Off / horizontal mirroring / vertical mirroring / 180° rotation

Image Setting

Brightness / contrast / sharpness / saturation / chroma

Responding Speed

≤1s

Maximum Detection

5fps/s (color image)

Detection Area

Support specified area, default full screen

Shielded Area

Support 4 areas setting

Upload Method

Private protocol upload

Trigger Method

Video trigger

Encoding Format

H.265+ / H.265/H.264

Coding Characteristics

Main stream: 8MP(3840X2160)20fps, 5MP(3072X1728@25fps),
4MP(2560X1440@25fps), 3MP(2304X1296@25fps), 2MP(1920X1080@25fps)
Sub stream: D1(720X576), VGA(640X480), Q720P(640X360)

Video Bit Rate

Fixed bit rate, variable bit rate(1280kbps-4Mbps)

Video Type

Composite stream / video stream

Audio Coding Standard

G.711U/64Kbps

Network Interface

1*RJ45 10M/100M self-adaptive LAN port

Network Protocol

TCP/IP, UDP, HTTP, DHCP, RTSP, NTP

Interface Protocol

ONVIF

Network Interface

RJ45 10M/100M network adaptive

PoE

External PoE

TF Card Slot

Up to 512G, Micro SD (EXT3/EXT4) card local storage

Audio

Built-in MIC & Speaker

Alarm

1 in 1 out

Operation T/H

-20°C~55°C / 0%-90%

Weatherproof

IP 66

Power Supply

DC12V / PoE

Power Consumption

<10W (MAX)
