ST-IP-DM-003- 2MP IP Full Color Camera

Main Chipset

T31N

Image Sensor

1/2.9″, 2MP progressive scan ultra-low illumination CMOS GC2063

Effective Pixels

2MP

Min. Illumination

Color : 0.1Lux@F1.2; B&W : 0Lux@F1.2(IR on)

Lens

F1.6 2.8mm

IR Distance

20-30M (4 x Warmlight)

Noise Reduction

3D noise reduction

WDR

DWDR (off / low / medium / high)

Mirror

Off / horizontal mirroring / vertical mirroring / 180 ° rotation

Image Setting

Brightness / contrast / sharpness / saturation / chroma

Encoding Format

H.265/H.264

Coding Characteristics

Main stream: 2MP 1920×1080@25fps, 1280×720
Sub stream:D1(720*576), VGA(640*480), Q720P(640*360), CIF(352*288)

Video Bit Rate

Fixed bit rate, variable bit rate(1280kbps-4Mbps)

Video Type

Composite stream / video stream

Audio Coding Standard

G.711U/64Kbps

Audio

Built-in MIC

Network Interface

1*RJ45 10M/100M self-adaptive LAN port

Network Protocol

TCP/IP, UDP, HTTP, DHCP, RTSP, NTP

Interface Protocol

ONVIF

Network Interface

RJ45 10M/100M network adaptive

PoE

Built-in PoE

PoE

Built-in PoE

Operation T/H

– 20°C ~ 55°C / 0%-90%

Power Supply

DC12V / PoE

Power Consumption

<10W (MAX)
