MK2120UL IriShield USB

Product Description

Technical Specifications

• Capture Mode: Auto
• Capture Distance : 14.0 cm – 15.0 cm (5.5 inches – 6.0 inches) from the image sensor (optimal distance = 14.5 cm (5.7 inches)), Focal depth = 1.0 cm (0.4 inch)
• Sensor Resolution : VGA
• Dimensions: 51.2 mm x 92.6 mm x 15.1 mm (2 inches x 3.6 inches x 0.59 inch)
• Power: Single USB Bus Powered (DC +5V±5%) (Max power consumption = 300mA)
• Illumination: Near infrared LED
• Environmental: -20°C to +60°C (Storage); 0°C to +50°C (Operating); 10% to 90% Humidity (Non-Condensing)*
• Usage: Indoor; Outdoor (avoid direct sunlight and bright re‑ections)
• Compliance & Certificates: Eye safety standard (IEC 62471:2006-07), RoHS, FCC-Class B, IP54
• Resolution: Spatial : 50% @ 3.5 Lp/mm, Pixel :  16 Pixels/mm
• Connectivity: USB 2.0
• Security: RSA (2048-bit) and AES (256-bit); X509 Certi­cate, PFX/PKCS#12 Certi­cate,  RSA key pair generated on-board
• Ancillary SW: Drivers, SDK (C/C++, .NET, C#/VB, Java), Demo Application with Sample codes
• Host OS: Windows Family, Linux Family, WinCE, Embedded Linux, Android, Mac, proprietary OS or Non-OS
