M.2 SATA Solid State Drive

Technical Specifications

System Requirements

• Operating System: Supported by all operating systems
• Operating Voltage Req: Vcc = 3.3V +/-5%
• Interface: SATA 6.0Gbps (SATA‐III) or SATA 3.0Gbps (SATA‐II) or SATA 1.5Gbps

• Length: 80.0 ± 0.2 mm
• Width: 22.0± 0.2 mm
• Thickness: 2.20 ± 0.15 mm
• Weight: <7.0g
• Data Transfer Speed (R / W)
• Seq. Read / Write: 530* MB/s / 515* MB/s (128GB, 256GB, 512GB, 1TB)

• Access Time: 0.2 ms
• Seek Time: 0 ms
• Mount Time: Dependent on system HW and SW
• Power on to Ready: Dependent on system HW and SW
• Data Transfer Time: Rated Data Transfer Speeds are maximums based on Crystal Disk Mark 6.0

• Operating Temperature: Commercial Grade: 0°C to +70°C, Industrial Grade: -40°C to +85°C
• Humidity: 5% to ~98% RH
• Operating Shock: 1500G
• Operating Vibration: 16G
• Operating Altitude: TBD
