IP Dome Wifi Camera S-IP-3MD-WFA

Technical Specification

System

• Main Processor: HiSilicon 3516E, High- performance processor
• Sensor: 1/2.7, 3Megapixel progressive scan CMOS
• Image Compression: H264 / H.265 ( Default is H264, can be set H.265 by IE browser )

• Lens Parameter : Focal length: 4mm, 3MP
• Angle of View: Horizontal: 73°, Vertical: 53.6°, Diagonal: 95,2°

• Resolution : 1296P(2304×1296) / 1080P(1920×1080) / 720P(1280×720) / VGA(640×480)
• Image Frame Rate: Main stream: 3MP(15fps – 25fps) / Sub stream: VGA(25fps)
• Automatic Exposure: Adjust the image automatically to view clearly
• Infrared Mode : Automatic
• Night Visibility: 2 PCS array IR illumination LEDs, IR range up to 15 meters
• Min.Illumination : 0.01 Lux / F1.2 (With IR Illuminator)
• Zoom : App supports 3x digital zoom
• Audio : Built-in Mic & Speaker, supports two-way audio

• Alarm: Motion detection alarm
• Alarm Notification: Push alarm notifications to your smartphone
• Advanced Zone Detection: Set customized motion detection zones to control what you’re monitoring

• Privacy Protection : System defaults the first user as administrator, other users accessing the  camera need administrator’s authorization, otherwise they can’t view it
• Privacy Block:Set up to 4 privacy areas

• Remote Access : P2P
• Ethernet : RJ-45
• Wireless : 2.46 IEEE 802.11 b/gIn, supports WEP, WPA & WPA2 Encryption
• AP Hotspot: With wireless access point, camera can be connected to phone without router
• Protocol: IPV4, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Filter, QoS
• Interoperability: Onvif

• App: iOS &Android
• Windows PC CMS: HCMS, ONVIF Device Manager, Blue Iris, ispy etc.
• Web Browser: Internet Explorer

• Record Mode: Motion detection alarm recording, 7/24 recording
• Record Standard: HD mode(1296P/1080P/720P) / SD mode(360P)
• Storage: MicroSD card (Max 128GB), Local and FTP storage
• Playback: Remote and local record playback

• Product Type: Plastic Dome type, indoor use
• Power Supply: DC 12V
• Working Temperature: -10°C — 50°C
• Working Humidity: 10% to 90% RH
• Weight: N.W.:232g, G.W.:420g (Note:Actual Weight Final)
• Accessories  : Adaptor, User Manual, Screws, & LAN Cable
• Size: Item size: 118’118900 mm (LxWxH), Packaging size: 152’135909mm (LxWxH)
• Certification: CE, FCC & RoHS
