9CH 1HDD 4K H.265 Intelligent NVR- ST-NVR-001

Main Chipset

SSR621Q

Operating System

Embedded Linux

Bandwidth

64M

Video Format

H.265/H.264

Video Maximum Resolution

Main Stream: 3840*2160

Record Mode

Sub Stream: 720*576

Backup Mode

Manual, Schedule, Motion Detection, Timing, Alarm, Stop USB Device/Network

Video Stream Mode

Main stream+sub stream

Video Input

16Ch Digital (8MP/D1) + 16Ch Preview + 4Ch Playback

Video Output

1 HDMI, 1 VGA

Audio Output

3840×2160/30Hz, 2560×1440/30Hz, 1920×1080/60Hz, 1440×900/60Hz, 1366×768/60Hz, 1280×1024/60Hz, 1280×800/60Hz, 1024×768/60Hz HDMI / 3.5mm Audio Output

HDD

1 SATA, MAX 10TB HDD

Network Interface

1*RJ45 10M/100M self-adaptive LAN port

Network Function

DDNS, EMAIL, UPNP, NTP, DHCP, IP Filter, PPPoE, P2P

Smart Phone

iPhone, Android

USB

2 USB Ports (USB2.0)

Power Supply

DC12V 2A

Power Consumption

≤10W (without HDD)
