16 PON PORTS GPON OLT S-OLT-GPON-16OLT-L3D
Product Details:
X
Product Description
Chassis:
- Rack: 1U 19 inch standard box
1G/10GUplink Port
- QTY: 12
- 1G Copper Port auto-negotiation(RJ45) :8
- SFP 1GE/SFP+ 10GE: 4
GPON Port
- QTY : 16
- Physical Interface: SFP Slot
- Connector Type: Class C+
- Max splitting ratio: 1:128
Management Ports:
- 1*10/100BASE-T out-band port, 1*CONSOLE port
PON Port Specification(Class C+ module):
- Transmission Distance: 20KM
- GPON port speed: Upstream 1.244G, Downstream 2.488G
- Wavelength: TX 1490nm, RX 1310nm
- Connector: SC/UPC
- Fiber Type: 9/125μm SMF
- TX Power: +3~+7dBm
- Rx Sensitivity: -30dBm
- Saturation Optical Power: -12dBm
- Dimension(L*W*H) : 442*320*43.6mm
- Weight : 4.5kg
- AC Power Supply: AC:100～240V, 47/63Hz
- DC Power Supply :(DC:-48V) √
- Double Power Module Hot Backup : √
- Power Consumption : 85W
Operating Environment:
- Working Temperature: 0～+50℃
- Storage Temperature : -40～+85℃
- Relative Humidity: 5～90%(non-conditioning)
